Food Skin Packaging Machine
Automatic Food Skin Packaging Machine IDEAL-410 model -Suitable for bulk food skin packaging production. Almost automatic cutting film skin packaging machine are customized according to customer's request. This machine output can be four or three or two according to tray size.And it is suitable to skin packaging seafood,meat,fruit, poulary etc food.The skin packaging effect is excellent.
The IDEAL-410 is an automatic vacuum skin packaging machine designed for food processors that need higher efficiency, more consistent film handling and flexible tray formats for medium-volume production.
The food tray skin packaging machine combines automatic film feeding, photoelectric film positioning and automatic film cutting with controlled heating, vacuum forming and skin sealing. Depending on tray dimensions and mold layout, the IDEAL-410 can accommodate two, three or four trays in each packaging cycle.
This automatic food skin packaging machine is suitable for fresh meat, steak, poultry, seafood and selected prepared food applications. It is especially suitable for food factories moving beyond manual film handling but not yet requiring a large continuous conveyor packaging line.
For other output levels and food tray skin packaging machine configurations, view our complete range of food skin packaging machines.
The IDEAL-410 automatic vacuum skin packaging machine is configured according to the selected tray, skin film, product dimensions and required output. The mold working area should not be interpreted as the maximum size of one tray. Final tray dimensions and cavity layout must be approved through tray drawings or physical sample testing.
|
IDEAL-410 Model |
|
1.Working Voltage:380V 50HZ 2.Heater:5KW/H 3.Mold Size:640x490mm 4.Speed:2-3cycle/min 5.Applied Film Width:Max 560mm 6.Vacuum Pump:0.6-0.8Mpa 7.Machine Size:1400x1350x1530mm
|
|
Main Feature: 1. Machine Control System: Adopt famous Brand programming controller, 7-inch color simulation touch screen. 2.Film Feeding System: high-speed&high-precision positioning film feeding design with photoelectric tracking and system control. 3.Mold: 6061 aluminum alloy mold,Oxidation treatment results in high strength and corrosion resistance, meeting food hygiene requirements. 4.Machine Frame:304SS material which resists deformation and ensures greater durability. 5.The mold of packaging and cutting adopt an independent guide post structure to ensure precision and zero error. 6.Sealing gasket: Imported silicone gasket with good toughness and better sealing effect. |
The IDEAL-410 can be configured as a VSP machine for meat and seafood products packed in compatible preformed trays. Because different foods place different demands on the film, mold and vacuum process, each application should be evaluated before commercial production.
| Application | Key Packaging Points to Verify |
|---|---|
| Fresh steak and boneless meat | Film clarity, seal integrity, purge control and tray flange cleanliness |
| Bone-in meat | Film puncture resistance and protection around exposed bone |
| Fish fillets | Product moisture, film drape and sealing-surface contamination |
| Shellfish | Sharp-shell puncture resistance and product protrusion |
| Poultry portions | Irregular product contours, product height and sealing consistency |
| Frozen food | Film flexibility and seal stability at the required storage temperature |
For high-oxygen-barrier applications, buyers can evaluate EVOH high-barrier skin film. Products with bones, shells or sharp profiles should be tested with a suitable anti-puncture film.
The final packaging result should be verified using the actual food product, selected food skin packaging tray and production film.
The IDEAL-410 automatic vacuum skin packaging machine can be equipped with customized mold layouts based on the size of the food tray.
Typical arrangements include:
| Mold Layout | At 2 Cycles/Min | At 3 Cycles/Min | Recommended Use |
| 2 trays per cycle | 240 trays/hour | 360 trays/hour | Larger meat, seafood or ready meal trays |
| 3 trays per cycle | 360 trays/hour | 540 trays/hour | Medium-sized retail food trays |
| 4 trays per cycle | 480 trays/hour | 720 trays/hour | Smaller portion trays and higher pack output |
The final tray quantity per cycle depends on:
The mold size should not be treated as the maximum size of one tray. Buyers should provide an actual tray sample or technical drawing before mold production.
A compatible food skin packaging film should be selected according to:
Available film options include:
EVOH high-barrier film can be evaluated for products requiring stronger oxygen barrier performance, subject to the tray material and storage requirements.
For products entering frozen storage, use a food frozen film for automatic machines designed to maintain flexibility under the intended low-temperature conditions.
Bone-in meat, seafood shells and sharp product profiles may require anti-puncture vacuum skin film.
Before bulk production, the selected film should be tested with the actual tray, food product and IDEAL-410 machine settings.
A reliable vacuum skin package depends on the compatibility between the machine, mold, film and tray sealing surface.
IDEAL supplies different food skin packaging trays for commercial food packaging projects.
Available tray options include:
Plastic vacuum skin trays provide a rigid base for meat, poultry, seafood, cheese and prepared food packaging.
Skin pack paper trays can be evaluated for brands seeking a paper-based retail presentation.
When standard tray sizes do not match the product or mold layout, IDEAL can develop a customized skin pack tray according to the required size, depth, cavity shape and packaging format.
Before selecting a tray, confirm:
The IDEAL-410 uses 6061 aluminum alloy molds with oxidation treatment to provide strength, corrosion resistance and a stable working surface for repeated production.
Custom molds can be developed according to:
The packaging and cutting mold sections use an independent guide-post structure to support stable alignment and cutting consistency during machine operation.
When ordering a mold, provide:
The IDEAL-410 uses a programmable control system and 7-inch color touchscreen for machine operation and packaging parameter adjustment.
The control system allows operators to manage the packaging cycle more clearly and repeat suitable settings for regular products.
Different combinations of film, tray and food may require different heating, vacuum and forming parameters. Packaging trials are recommended before commercial production.
The machine frame is made from 304 stainless steel to provide a durable external structure for food packaging environments.
The mold uses oxidation-treated 6061 aluminum alloy, while the imported silicone sealing gasket supports vacuum sealing during repeated cycles.
Routine maintenance should include:
Cleaning procedures should follow the machine manual and the food processor’s internal hygiene requirements.
